Heat Resistant Conveyor Belt
Product features:
A- Suitable for conveying hot material like powder or clump materials at high temperature.
B- Ideal for conveying sintered ores, cokes, soda ash, chemical fertilizer, slag and foundry.
C- It can resist high temperature.
D- The rubber compound used in the cover have been designed to avoid premature aging due to contact with any source of heat.
E- Heat resistant conveyor belt can be divided into three types according to working temperature range: HRT-1 ≤100°C, HRT-2≤125°C, HRT-3≤150°C.
Models:
Heat resistant conveyor belts fall into three models
Mode1: able to with stand the test temperature of less than 100°C, code S1
Mode2: able to with stand the test temperature of less than 125°C, code S2
Mode3: able to with stand the test temperature of less than 150°C, code S3
Mode4: able to with stand the test temperature of less than 175°C, code S4
The physical performance of cover rubber after heat-proof test comform to the specification in the table
| Index |
Model |
| Model1 |
Model2 |
Model3 |
Model4 |
| Variation range |
| Hardness |
Difference after and before aging(IRHD) |
20 |
±20 |
±20 |
| Maxmum after aging(IRHD) |
85 |
| Tensile strength |
Decrease of performance variance rate %<= |
-25 |
-30 |
-40 |
-40 |
| Maxmum after aging Mpa |
12 |
10 |
5 |
5 |
| elongation at break |
Performance variance rate % |
-50 |
-55 |
-55 |
| Maxmum after aging % |
200 |
180 |
180 |
Adhesion of inter layer
| Index |
Between faberic layers |
Between cover layer and belt core |
| Cover layer thickness 0.8-1.5mm |
Cover layer thickness>1.5mm |
| Average of all test samples,N/mm no less than |
3.0 |
2.2 |
2.6 |
| The lowest data of all test samples,N/mm,no less than |
2.0 |
1.6 |
2.0 |
|
|
|
